Description
Natural Elegance, Optimal Airflow
The ProArt PA401 Wood Edition showcases a wooden front panel that creates a distinctive, elegant style while promoting sustainability. The wood used is certified by the Forest Stewardship Council® (FSC®), and is finished using a six-stage process. The case also boasts optimal built-in cooling, with two 160mm front fans and one 120mm rear fan, along with an integrated fan hub, enabling optimal airflow.
Exceptional Cooling Performance
The PA401 Wood Edition features a front grille with 33% porosity to maximize airflow and ventilation. Meanwhile, built-in dual 160mm front fans efficiently deliver up to 138cfm of airflow to graphics cards and CPU coolers, and the outer ring connecting these fan blades helps reduce initial vibration. The front fans and the 120mm rear fan with PWM control yield optimal airflow, low noise, low vibration and high reliability.
Crafted Wood
Ash wood, an uncommon choice for this style of case, has been selected for its durability. The special six-stage production process used to create the front panel begins with thermowood treatment, protecting the wood from insects, humidity and heat. The panel material is then shaped to exact specification. Finally, a two-step coating elevates the unique Ash grain with a glossy finish.
The ash wood used for ProArt PA401 Wood Edition is sustainably sourced and is certified by the FSC®.
Flexible, Fast I/O
Connectivity options are easily accessible via the front I/O panel, including one two-section PWM control, one 20Gbps USB Type-C® port, two USB-A 3.0 ports, HD audio and a Power and Reset button lock.
Builder-Friendly Installation
The ProArt PA401 Wood Edition optimizes the PC building experience, offering better functionality with user-focused features.
- Model
ProArt PA401 Wood Edition – Tempered Glass Panel - Motherboard Support
ATX - Drive Bays
2 x 2.5″ Bay
2 x 2.5″/3.5″ Combo Bay - Expansion Slots
7 - Front I/O Port
1 x headphone / Microphone
2 x USB 3.2 Gen1
1 x USB 3.2 Gen 2×2 Type C - Radiator Support (Top)
120 mm
140 mm
240 mm - Cooling Support (Front)
2 x 140 mm
2 x 160 mm - Cooling Support (Top)
2 x 120 mm
2 x 140 mm - Cooling Support (Rear)
1 x 120 mm - Pre-installed Fans (Front)
2 x 160 mm - Pre-installed Fans (Rear)
1 x 120 mm - Maximum CPU Cooler Height
160 mm - Maximum GPU Length
315 mm - Maximum PSU Length
170 mm - Removable Dust Filters
Front
Bottom - Dimensions
412 x 225 x 503 mm (D*W *H) - Weight
8.61 Kg - Accessory
Pre-installed Fan Hub Support PWM Fan Output x 5
