Gigabyte Eagle RTX 5070 OC ICE SFF Edition 12GB

Description

FEATURES

• Powered by the NVIDIA Blackwell architecture and DLSS 4
• Powered by GeForce RTX™ 5070
• Integrated with 12GB GDDR7 192bit memory interface
• WINDFORCE cooling system
  Hawk fan
  Server-grade Thermal conductive gel
• NVIDIA SFF-ready
• RGB Lighting
• Reinforced structure

WINDFORCE COOLING SYSTEM

The WINDFORCE cooling system delivers exceptional thermal performance through a combination of cutting-edge technologies. It features server-grade thermal conductive gel, innovative Hawk fans with alternate spinning, composite copper heat pipes, a large copper plate, 3D active fans, and screen cooling.

ASTONISHING EXTERIOR DESIGN

The design inspiration for the EAGLE series stems from the fusion of aerospace battleships and sci-fi elements. Its unique curved contours outline a streamlined appearance, complemented by segmented lines resembling disassembled deck components, evoking the intricate structure of a spaceship. This design infuses the overall aesthetic with a rich cosmic technology vibe, showcasing the futuristic aesthetics and craftsmanship in every detail.

SIGNATURE IDENTITY

The frontal design boldly integrates aerospace and sci-fi elements, clearly showcasing the distinctive EAGLE style, while maintaining a cohesive aesthetic with the motherboard product line. This ensures a unified design language and reinforces product family identity.

DYNAMIC PULSATING VISUAL

The side panels adopt a layered metal plate design to enhance the depth and dynamics of the pulsating elements. Combined with subtle blue lighting effects, it crafts an immersive sci-fi visual aesthetic.

NVIDIA SFF-READY

Complying with NVIDIA’s small form factor specification, our graphics cards pack powerful performance into a small form factor, achieving the perfect balance of size and power.

• Graphics Processing
  GeForce RTX™ 5070
• Core Clock
  2587 MHz (Reference card : 2512 MHz)
• CUDA® Cores
  6144
• Memory Clock
  28 Gbps
• Memory Size
  12 GB
• Memory Type
  GDDR7
• Memory Bus
  192 bit
• Card Bus
  PCI-E 5.0
• Digital max resolution
  7680×4320
• Multi-view
  4
• Card size
  L=290 W=120 H=50 mm
• PCB Form
  ATX
• DirectX
  DirectX 12 API
• OpenGL
  4.6
• Recommended PSU
  750W
• Power Connectors
  16 Pin*1
• Output
  DisplayPort 2.1b *3
  HDMI 2.1b *1
• Accessories
  1. Quick guide
  2. 1x 12V-2×6 to 2x PCIe 8pin adapter
