Description
Wave 2
The DAP-2610 Wireless AC1300 Wave 2 Dual-Band PoE Access Point is designed to support small to medium business or enterprise environments by providing network administrators with secure and manageable dual-band wireless LAN options, and utilising the cutting-edge speed of 802.11ac Wave 2.
Business Class Wi-Fi.
With simultaneous dual-band, PoE support, extensive manageability, versatile operation modes, and robust security enhancements, the DAP-2610 Wireless AC1300 Wave 2 Dual-Band PoE Access Point provides a reliable solution for deploying a business-class wireless network.
Enterprise Wireless Performance
The DAP-2610 delivers reliable, high-speed wireless performance using the latest 802.11ac Wave 2 standard with wireless signal rates of up to 1.3 Gbps (400 Mbps over the 2.4 GHz band and 900 Mbps over the 5 GHz band).
Technology that makes a difference
MU-MIMO allows multiple devices to get high-bandwidth Wi-Fi signal at the same time, distributing data more efficiently. Beamforming improves coverage and speed by directing Wi-Fi signal directly to the client device. Band Steering automatically connects each device on the network to the best, clearest band available for the best connection.
Guest access control
Provide Guest access with a Captive Portal. Combine it with RADIUS authentication and Dynamic VLAN for Guest bandwidth and access control.
Flexible deployment
With 802.3af Power over Ethernet (PoE) support, you can easily install in areas where power outlets are not available. WDS support allow multiple DAP-2610s to bridge with one another, while also providing network access to individual clients. Additionally, advanced features such as load balancing and redundancy ensure fail-safe wireless connectivity.
Specifications
|
Type
|
Software Managed AP |
|---|---|
|
Wireless standard
|
Wireless AC Wave 2 |
|
Frequency band mode
|
Dual-band simultaneous |
|
Wireless speed
|
867 Mbps 5 GHz 400 Mbps 2.4 GHz |
|
Advanced features
|
MU-MIMO 802.11k/r Roaming SmartBeam |
|
Antenna type
|
Embedded omni-directional antennas |
|
Antenna gain
|
3 dBi for 2.4 GHz 3 dBi for 5 GHz |
|
Power-over-Ethernet
|
Yes |
|
Wired interface
|
1 x Gigabit Ethernet LAN |
|
Indoor/outdoor
|
Indoor |
|
Type of housing
|
Plastic |
|
Wireless modes
|
Access Point (AP) WDS bridge WDS with AP Wireless client |
|
Maximum number of SSIDs
|
8 per radio |
|
Auto channel selection
|
✔
|
|
WMM-PS/802.11e (U-APSD)
|
✔
|
|
Wi-Fi scheduler
|
✔
|
|
AP traffic load balance
|
✔
|
|
L2 roaming
|
✔
|
|
WEP 64/128 bit
|
✔
|
|
WPA/WPA2-Personal/Enterprise
|
✔
|
|
TKIP/AES encryption
|
✔
|
|
WPA_WPA2_PSK over WDS
|
✔
|
|
WLAN partition
|
✔
|
|
SSID broadcast disable
|
✔
|
|
Rogue AP detection
|
✔
|
|
Station isolation
|
✔
|
|
MAC address filtering
|
✔
|
|
802.1X authentication
|
✔
|
|
DHCP server
|
✔
|
|
802.1D STP
|
✔
|
|
IGMP snooping
|
✔
|
|
ARP spoofing
|
✔
|
|
NTP
|
✔
|
|
IPv6
|
✔
|
|
WEB
|
✔
|
|
SNMP (v1, v2c, v3)
|
✔
|
|
CLI
|
✔
|
|
Telnet
|
✔
|
|
SSH
|
✔
|
|
Syslog
|
✔
|
|
Management platform
|
Nuclias Connect |
