Description

ColorVu & IR Acusense Network Speed Dome

• Image Sensor: [Bullet channel]: 1/1.8″ Progressive Scan CMOS; [PTZ channel]: 1/1.8″ progressive scan CMOS
• Max. Resolution: [Bullet channel] 2560 × 1440, [PTZ channel] 2560 × 1440
• Min. Illumination:

  [Bullet channel]: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light;

  [PTZ channel]: Color: 0.005 Lux @ (F1.5, AGC ON), B/W: 0.001 Lux @ (F1.5, AGC ON), 0 Lux with IR

• Shutter Speed: 1 s to 1/30,000 s
• Day & Night: ICR
• Zoom: [PTZ channel] 32 × optical, 16 × digital
• Slow Shutter: yes
• HLC: yes
• 3D DNR: yes

Lens

• Focal Length: [Bullet channel]: 4 mm; [PTZ channel]: 5.9 to 188.8 mm, 32 × optical
• FOV:

  [Bullet channel]: Horizontal field of view: 88.7°, Vertical field of view: 44.7°;

  [PTZ channel]: Horizontal field of view: 60.2° to 2.3°, vertical field of view: 35.2° to 1.3° (wide-tele)

• Focus: semi-auto||manual||auto
• Aperture: [Bullet channel]: F1.0; [PTZ channel]: F1.5
• Zoom Speed: [PTZ channel]: approx. 5.6 s

Illuminator

• Supplement Light Type: [Bullet channel] white light, [PTZ channel] IR
• Supplement Light Range: [Bullet channel] white light: up to 30 m, [PTZ channel] IR: up to 200 m
• Smart Supplement Light: Yes

PTZ

• Movement Range (Pan): 360°
• Movement Range (Tilt): -15° to 90° (auto flip)
• Pan Speed: pan speed: configurable from 0.1° to 160°/s; preset speed: 240°/s
• Tilt Speed: tilt speed: configurable from 0.1° to 120°/s, preset speed 200°/s
• Proportional Pan: yes
• Presets: 300
• Preset Freezing: yes
• Patrol Scan: 8 patrols, up to 32 presets for each patrol
• Pattern Scan: 4 pattern scans
• Park Action: preset||pattern scan||patrol scan||auto scan||tilt scan||random scan||frame scan||panorama scan
• 3D Positioning: yes
• PTZ Status Display: yes
• Scheduled Task: preset||pattern scan||patrol scan||auto scan||tilt scan||random scan||frame scan||panorama scan||dome reboot||dome adjust||aux output
• Power-off Memory: yes

Video

• Main Stream:

  [Bullet channel]:

  50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)

  60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)

  [PTZ channel]:

  50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)

  60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)

• Sub-Stream:

  [Bullet channel]:

  50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288)

  60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)

  [PTZ channel]:

  50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288)

  60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)

• Third Stream:

  [Bullet channel]:

  50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)

  60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)

  [PTZ channel]:

  50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)

  60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)

• Video Compression: H.265||H.264||MJPEG
• Video Bit Rate: 32 kbps to 16384 kbps
• H.264 Type: baseline profile||main profile||high profile
• H.265 Type: main profile
• Scalable Video Coding (SVC): yes
• Region of Interest (ROI): main stream, sub-stream and third stream respectively support eight fixed areas

Audio

• Audio Compression: G.711,G.722.1,G.726,MP2L2,PCM
• Audio Bit Rate: 32 to 192 Kbps (MP2L2)
• Audio Sampling Rate: 8 kHz,16 kHz,32 kHz,48 kHz
• Environment Noise Filtering: yes

Network

• Protocols: IPv4/IPv6||HTTP||HTTPS||802.1x||Qos||FTP||SMTP||UPnP||SNMP||DNS||DDNS||NTP||RTSP||RTCP||RTP||TCP/IP||UDP||IGMP||ICMP||DHCP||PPPoE||Bonjour
• Simultaneous Live View: 20
• API: Open-ended API, Open Network Video Interface (Profile S, Profile G), ISAPI, Hikvision SDK, Third-party management platform, ISUP
• User/Host: 32
• Security: Authenticated username and password||MAC address binding||HTTPS encryption||802.1X authenticated access||IP address filter
• Network Storage: NAS (NFS，SMB/ CIFS), ANR
• Client: iVMS-4200||Hik-Connect
• Web Browser: IE 10+, Chrome 57+, Firefox 52+, Safari 12+


• Image Parameters Switch: Yes
• Image Settings: saturation||brightness||contrast||sharpness
• Day/Night Switch: day, night, auto, scheduled-switch
• Wide Dynamic Range (WDR): 120 dB WDR
• SNR: 52dB
• Defog: yes
• Image Stabilization: EIS (Built-in gyroscope to improve EIS performance)
• Image Enhancement: BLC, HLC, 3D DNR
• Privacy Mask: [Bullet channel] 8 programmable polygon privacy masks, [PTZ channel] 24 programmable polygon privacy masks; mask color or mosaic configurable
• Regional Focus: yes
• Regional Exposure: yes

Interface

• Ethernet Interface: RJ45, self-adaptive 10M/100M Ethernet port
• On-board Storage: Built-in memory card slot, support Micro SD/Micro SDHC/Micro SDXC, up to 256 GB
• Audio:

  1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%,

  1 output (line out), line level, output impedance: 600 Ω

• Alarm: 2 input(s), 1 output(s)
• Reset: yes

Event

• Basic Event: [PTZ channel] motion detection, video tampering alarm,[PTZ channel & bullet channel] alarm input and output, exception
• Smart Event: [PTZ channel & bullet channel] audio exception detection,[PTZ channel] line crossing detection, intrusion detection, region entrance detection, region exiting detection,[Bullet channel] line crossing detection, intrusion detection, region entrance detection, region exiting detection
• Linkage: [Bullet channel] Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, audible warning, white light flashing,[PTZ channel] Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, audible warning, white light flashing, and PTZ actions (such as preset, patrol scan, pattern scan)
• Smart Tracking: [PTZ channel] yes
• Smart Linkage: Manual tracking, auto tracking, tracking takeover, track in turn

Deep Learning Function

Face Capture: [Bullet channel] no,[PTZ channel] yes

General

• Power: 24 VAC, Hi-PoE
• Dimension: Ø 220 mm × 382.1 mm (Ø 8.66″ × 15.04″)
• Weight: Approx. 6 kg (13.23 lb.)
• Material: ADC12
• Operating Condition: -30℃ to 65℃ (-22°F to 149°F) ||humidity lower than 90%RH
• General Function: mirror, password protection, watermark, IP address filter
• Demist: Demist by heating the glass
• Power Consumption and Current: Max. 42 W, including max. 2.6 W for heater and max. 11 W for supplement light
