Description
- Large Display
- High Quality Display with up to 4k Resolution
- Extreme endurance – with option to run 24/7 all year round
- High durability with 4mm tempered glass
- Aesthetic modern design with slightly rounded corners and aluminium alloy frame
- Compatible with Landscape and Portrait orientations
- Perfect for the following applications:
- Boardroom presentation – & Video conferencing- display
- Executive office display
- Training room presentation – & Video conferencing -display
- Control room display
- Digital Signage display
Specifications
Panel
Screen Size: 100″
Backlight: D-LED
Resolution: 3840*2160
Brightness: 350cd/m²
Contrast: 1 to 1/10000s
Response time: 6,5ms
Pixel pitch: 0.19125 mm x 0.5735 mm
Frame rate: 60 Hz
View angle: 178°(H) / 178°(V)
Color saturation (x% NTSC): 72 %
Viewing area: 2203.2(H)×1239.3(V) mm
Chromaticity: 1.07B(8bit +Hi+FRC)
Life: 50,000 hrs
Motherboard: M679V
Power Parameters
Voltage: 100 V ~ 220 V, 50-60 Hz
Maximum power: ≤450W
Standby power: <0.5W
Working Envronment
Operating temperature: 0℃ ~ 40℃
Storage temperature: -10℃ ~ 60℃
Storage humidity: 10% ~ 60% RH Non-Condensing
Working humidity: 20% ~ 80% RH Non-Condensing
Features
Internal speaker: 8Ω/10W*2
Switch: 1
Interface
DP input: 1
HDMI input: 1
DVI input: 1
VGA input: 1
YPbPr input: 1
AV input: 1
USB interface(upgradeable,media playback): 1
USB interface(only Unicom and built-in USB): 1
Structure
Net weight: 135KG±1.5KG
Gross weight: 192.6KG±1.5KG
Bare machine size(length * width * height): 2275mm*110mm*1311mm
Packing size(length * width *height): 2500mm*440mm*1630mm
VESA hole position: 4-M10 screw hole 800*400
Shell material(top frame/rear panel): Aluminum profile/sheet metal
Shell color(top frame/rear panel): Full black
