Description
- Large Display
- High Quality Display with up to 4k Resolution
- Extreme endurance – with option to run 24/7 all year round
- High durability with 4mm tempered glass
- Aesthetic modern design with slightly rounded corners and aluminium alloy frame
- Compatible with Landscape and Portrait orientations
- Perfect for the following applications:
- Boardroom presentation – & Video conferencing- display
- Executive office display
- Training room presentation – & Video conferencing -display
- Control room display
- Digital Signage display
Specifications
Panel
Screen size: 85″
Backlight: D-LED
Resolution: 3840*2160
Brightness: 350cd/m²
Contrast: 1 to 1/10000s
Response time: 6ms
Pixel pitch: 0.4875 mm x 0.4875 mm
Frame rate: 60 Hz
View angle: 178°(H) / 178°(V)
Color saturation (x% NTSC): 72 %
Viewing area: Support
Chromaticity: 1.07B(8bit)
Life: 50,000 hrs
Motherboard: M679V
Power Parameters
Voltage: 100 V ~ 220 V, 50-60 Hz
Maximum power: ≤350W
Standby power: <0.5W
Working Environment
Operating temperature: 0℃ ~ 40℃
Storage temperature: -10℃ ~ 60℃
Storage humidity: 10% ~ 60% RH Non-Condensing
Working humidity: 20% ~ 80% RH Non-Condensing
Features
Internal speaker: Auto
Switch: 1
Interface
DP input: 1
HDMI input: 1
DVI input: 1
VGA input: 1
YPbPr input: 1
AV input: 1
USB interface(upgradeable,media playback): 1
USB interface(only Unicom and built-in USB): 1
Structure
Net weight: 86KG±1.5KG
Gross weight: 103.3KG±1.5KG
Bare machine size(length * width *height): 1952.6mm*97.6mm*1106mm
Packing size(length * width *height): 2110MM*240mm*1315mm
VESA hole position: 4-M8 screw hole 600mm*400mm
Shell material: Aluminum profile/sheet metal
Shell color: Full black
